Description ASRock X570 Extreme4 Motherboard

X570 Extreme4

Supports by

• AMD processors AM4 Ryzen 2000 and 3000 processors
• Power system 10
• Support DDR4 4666 + (OC)
• 2 PCIe 4.0 x16, 3 PCIe 4.0 x1, 1 M.2 (Key E) for the WiFi support
• AMD Quad CrossFireX and CrossFireX
• Device of graphic data output: HDMI
• 7.1-channel HD codec (Audiokodek Realtek ALC1220), DTS Connect Support
• 8 SATA3, 1 of Hyper M.2 (PCIe Gen4 x4 & SATA3), 1 Hyper M.2 (PCIe Gen4 x4)
Gen2
• 2 USB 3.2 (Back Type A+C), 11 USB 3.2 Gen1 (4 lobbies, 6 back, 1 frontal types C)
• Intel Gigabit LAN
• ASRock Polychrome SYNC

REVOLUTIONARY MATERINKI X570

Transformation of your PC. Style. Reliability. Accurate design.

Steel PCI-E connectors

Steel PCI-E connectors have protection which excludes an interference of a signal of video cards. In these connectors even big and heavy video cards will be installed most reliably.

Double connector hyper-M.2 for SSD

Supports by

next generation of the drives PCI Express of 4.0 M.2 SSD, can gather speed three times above, than the interface of the 3rd generation, providing superfast data transmission.

Flexible protection of the back panel

Unlike most vendors, we give big freedom of action, offering for back ports a stub with the configured size that it ideally entered the case without mechanical inaccuracies.

10-PHASE FEED CIRCUIT

Has durable components and evenly CPU supplies. Besides, differs in unsurpassed opportunities for an overkloking with the smallest temperature for advanced gamers.

Dr. of MOS

Dr. of MOS is a built-in solution for optimization of synchronous giving of tension in any situations. Provides clever giving up to 50A of continuous current, improves thermal result and overall performance.

Dual USB 3.2 Gen2 (Type-A + Type-C)

Onboard USB connectors 3.2 Gen2 Type-A and Type-C with data transmission rate to 10Gbps.

Frontal USB connector 3.2 Gen1 Type-C Frontal USB connector 3.2 Gen1 Type-C provides

with

SPD to 5 Gbps and reverse design of the USB connector on a case panel perednya.

Premium throttles 60A

Throttles of a premium class of ASRock 60A three times more effective create a saturation current that provides the improved giving of a voltage of Vcore on the motherboard.

Diagnostics of Post Status Checker

This simple diagnostic tool shows to

status of the operations CPU/DRAM/VGA/BOOT at each start of a system. Post Status Checker allows to reveal a problem source quickly.

Purity Sound 4

With this motherboard you is waited by immersion to the world of the cleanest quality sound. The sound Purity Sound4 system is an onboard complex of hardware-software solutions. To a sound of format 7.1 HD with the latest Realtek ALC1220 codecs, separate micro payments for the left and right channels, a DAC 120dB SNR and other technologies providing is crystal an accurate sound.

Thunderbolt 3 AIC Connector

Thunderbolt 3 is is not limited to any more certain chipset. ASRock is the first vendor of motherboards who implemented Thunderbolt 3 technology on AMD X570 platform.

Aluminum radiator of XXL

Radiator of cooling of the large size effectively allocates for

heat from transistors and and a chipset, increasing stability of work of all system.

Throttles of Premium 60A Power Choke

In comparison with normal throttles, new throttles of a premium class from ASRock raise a saturation current by 3 times, providing more reliable voltage for the motherboard.

Dr. of MOS

Dr. of MOS is a built-in solution for optimization of synchronous giving of tension in any situations. Provides clever giving up to 50A of continuous current, improves thermal result and overall performance.

Throttles of memory of Premium Alloy Choke

Latest throttles developed for power of memory modules have high resistance to electromagnetic interferences and heat, and provide more stable and reliable power of the motherboard.

Combination of condensers 820uF and polymeric condensers 100uF guarantees

Combo condensers

clean, effective and more sympathetic power of CPU Vcore.

Black Nichicon 12K condensers

Superreliable black condensers 12K have service life not less than 12000 hours. Unlike other motherboards on which condensers hardly live till 10000 oclock ASRock offers Nichicon 12K Black Caps condensers with the service life prolonged for 20%, more reliable and stable.

Protection of I/O Armor

New technology of protection of the major components of the motherboard located at the back panel, uberezhyot a system from influence of static electricity.

Black opaque printed circuit board

Combination of black opaque color and copper shades is called by

High-End level components on ASRock motherboards.

Printed circuit board of high density

New design of the printed circuit board reduces gaps between layers and protects the motherboard from the electric short circuits caused by humidity.

by

Printed circuit board with a copper layer in 2 ounces

use only carefully selected copper samples for layers of the printed circuit board, and the technology allows to reduce temperatures and to improve energy efficiency at acceleration.

M.2 Key E Connector for Wi-Fi

Can connect separate Wi-fi module 802.11ac to special connector M.2 (Key E). (*Модуль Wi-Fi is not included in the delivery package.)

Some components of the motherboard are especially sensitive

Full Spike Protection

differences of tension, and redundant current on them can lead to instant failure of all system. The ASRock Full Spike Protection technology reliably protects these components of the motherboard from sudden power surges.

Characteristic ASRock X570 Extreme4 Motherboard

Article: span do not have X570_EXTREME4

• Form factor ATX
• Processor (socket type) AMD Socket AM4
• Model of the built-in processor
• Random access memory of DDR4 (quantity of slots), piece 4
• Random access memory of DDR3 (quantity of slots), piece there is no
• Random access memory of DDR2 (quantity of slots), piece there is no
• Chipset AMD X570
• Network connection (LAN RJ-45), Mbps 10/100/1000 Ethernet
• Wireless interfaces (Wi-Fi) there Is no

• Assignment for game PCs
• Form factor ATX
• Guarantee, month. 24
• Processor (socket type) AMD Socket AM4
• Processor (quantity of socket) 1
• Model of the built-in processor is not present
• Random access memory of DDR4 (quantity of slots), piece 4
• Random access memory of DDR3 (quantity of slots), piece there is no
• Random access memory of DDR2 (quantity of slots), piece there is no
• Random access memory (number of channels) 2nd channel
• Random access memory (ECC support) is
• Chipset AMD X570
• PCI Express Slot (PCI-E x16 (x16)), piece 2 of x PCI-E x16 (x16) of v4.x
• Slot of PCI Express (PCI-E x8), piece there is no
• Slot of PCI Express (PCI-E x4), piece there is no
• Slot of PCI Express (PCI-E x1), piece 3 of x PCI-E x1 v4.x
• Slot of PCI, piece there is no
• AGP Slot there is no
• Type-C/Thunderbolt 3 USB 3.1 Port 1 x USB 3.2 of Type C (Gen 2 up to 10Gbps)
• Gen 2 Type-A/Type-B/Type-CTM USB 3.1/3.2 Port (up to 10Gbps) 1 x USB 3.2 of Gen 2 Type-A
• Gen 1 Type-A/Type-B/micro USB USB 3.0/3.1/3.2 Port (up to 5Gbps) 2 x USB 3.2 of Gen 1 Type-A (on a payment, for a frontal output), 6 x USB 3.2 Gen 1 Type-A
• Type-A/Type-B/mini USB/micro USB USB 2.0 Port (up to 480Mbps) 2 x USB 2.0 Type-A (on a payment, for a frontal output)
• VGA (D-Sub) Port Is not present
• Port DVI, piece there is no
• HDMI (mini/micro) Port 1 x HDMI
• Thunderbolt Port span do not have 1 (5-pin on a payment)
• DisplayPort (mini/micro) Port
• PS/2 Port, piece there is no
• COM (RS-232) Port Is not present
• Port (IEEE 1394) is not present
• LPT Port (IEEE 1284), piece is not present
• Connector of the TPM module, piece 1 (on a payment)
• Number of SATA3 ports (6gbit/c), piece 8
• Number of SATA2 ports (3gbit/c), piece is not present
• Number of SATA Express ports (to 10gbit/c), piece is not present
• Slot of dimm.2, piece is not present
• Mini PCI Express (Mini PCI-E, span do not have Socket 3), piece 2 x M.2
• Support of program RAID RAID 0, RAID 1, RAID 10
• eSATA Port
• Quantity of eSATA, piece. do not have
• Number of IDE ports there is no
• Slot for FDD there is no
• Network connection (LAN RJ-45), Mbps 10/100/1000 Ethernet
• Network connection (quantity of LAN RJ-45), Mbps 1
• LAN controller Model Intel I211AT
• Wireless interfaces (Wi-Fi) there Is no
• Wireless interfaces (Bluetooth/NFC) there is no
• Built-in sound processor Realtek ALC1220
• Multichannel sound 7.1
• Will corrode 3.5 mm (mini-Jack), piece 5
• Optical output (S/PDIF) is
• Support of several video cards AMD CrossFireX, AMD Quad-GPU CrossFireX
• Built-in video there is no
• BIOS Ami, UEFI
• Cooling of the south bridge passive (radiator)
• General height of a product (H), mm 305
• General width of a product (W), the mm 244
• Illumination Is
• Colour Dark gray ules wet asphalt anthracite
• Main power connector 24 - pin
• Number of power connectors of coolers (total with CPU Fan), 6
