Description ASRock A320M-DVS Motherboard

Black sapphire

Deep black color. The basis in color of "black sapphire" gives to the motherboard a mysteriousness element.

Printed circuit board of high density

New design of the printed circuit board reduces gaps between layers and protects the motherboard from the electric short circuits caused by humidity.

Gigabit LAN Chip

is installed by

On this ASRock motherboard the network Realtek gigabit LAN chip with support of superhigh-speed connection with the Internet.

Two video outputs

At your disposal at once two often used video outputs, DVI and D-SUB from which it is possible to bring the image to external devices.

Solid-state condensers

On this motherboard the ASRock company used only solid-state condensers. The motherboard will work with such condensers more steadily at the increased service life.

Some components of the motherboard are especially sensitive

Full Spike Protection

differences of tension, and redundant current on them can lead to instant failure of all system. The ASRock Full Spike Protection technology reliably protects these components of the motherboard from sudden power surges.

ASRock APP Shop is created by

Live Update & APP Shop

for your convenience. We offer different applications and utilities for loading. Thanks to app store of ASRock APP Shop your motherboard and your system will always contain the latests version of software.

Characteristic ASRock A320M-DVS Motherboard

Article: span do not have A320M-DVS_R4.0

• Form factor micro-ATX
• Processor (socket type) AMD Socket AM4
• Random access memory of DDR4 (quantity of slots), piece 2
• Random access memory of DDR3 (quantity of slots), piece
• Random access memory of DDR2 (quantity of slots), piece there is no
• Chipset AMD A320
• Network connection (LAN RJ-45), Mbps 10/100/1000 Ethernet
• Wireless interfaces (Wi-Fi) there Is no

• Assignment for the desktop computer
• Form factor micro-ATX
• Guarantee, month 24
• Processor (socket type) AMD Socket AM4
• Processor (quantity of socket) 1
• Random access memory of DDR4 (quantity of slots), piece 2
• Random access memory of DDR3 (quantity of slots), piece is not present
• Random access memory of DDR2 (quantity of slots), piece there is no
• Random access memory (number of channels) 2nd channel
• Random access memory (ECC support) there is no
• Chipset AMD A320
• PCI Express Slot (PCI-E x16 (x16)), span do not have piece 1 of x PCI-E x16 (x16) of v3.x
• Slot of PCI Express (PCI-E x1), piece 1 of x PCI-E x1 v2.x
• Slot of PCI, piece
• AGP Slot there is no
• Gen 1 Type-A/Type-B/micro USB USB 3.0/3.1/3.2 Port (up to 5Gbps) 4 x USB 3.0/3.span do not have 1 Gen 1 Type-A (on a payment, for a frontal output)
• Type-A/Type-B/mini USB/micro USB USB 2.0 Port (up to 480Mbps) 2 x USB 2.0 Type-A
• VGA (D-Sub) Port 1 x VGA
• Port DVI, piece 1 x DVI-D
• PS/2 Port, piece 1
• COM (RS-232) Port
• Port (IEEE 1394) there is no
• LPT Port (IEEE 1284), piece there is no
• Connector of the TPM module, piece 1 (on a payment)
• Number of SATA3 ports (6gbit/c), piece 4
• Number of SATA2 ports (3gbit/c), span do not have piece
• Number of SATA Express ports (to 10gbit/c), span do not have piece
• Mini PCI Express (Mini PCI-E, Socket 3), piece 1 x M.2 (Key E)
• Support of program RAID RAID 0, RAID 1, RAID 10
• eSATA Port is not present
• Number of IDE ports there is no
• Slot for FDD there is no
• Network connection (LAN RJ-45), Mbps 10/100/1000 Ethernet
• Network connection (quantity of LAN RJ-45), Mbps 1
• LAN controller Model Realtek RTL8111H
• Wireless interfaces (Wi-Fi) there Is no
• Fastening for antenna Wi-Fi there is no
• Wireless interfaces (Bluetooth/NFC) there is no
• Built-in sound processor Realtek ALC887
• Multichannel sound 7.1
• I Will corrode 3.5 mm (mini-Jack), piece 3
• Optical output (S/PDIF) is not present
• BIOS AMI UEFI
• General height of a product (H), mm 230
• General width of a product (W), mm 201
• Illumination Is not present
• Colour Black
• Main power connector 24 - pin
• Complete set (cart-ny of change in different deliveries) 2 x of the SATA cables, a disk with software, a stub for the back panel of input-output, the installation instruction
