Description Ariston BLU EVO R 30/3 Boiler

ABS BLU EVO R — the accumulative water heater of the compact size with a tank covering fine enamel. Economy of space indoors thanks to a possibility of installation over or under a sink. Simplicity of installation — distinctive feature of this model.

Advantage:

• System of electric safety with the device of protective shutdown of ABS.
• Modern Italian design.
• Fine enamel.
• Welding of MICRO PLAZMA TIG.
• Testing of a tank at 16 atm.
• Increased magnesium anode for additional protection.
• Ease of management thanks to adjustment of temperature from the front panel.
• Simplicity of installation.
• System of distribution of water in NANOMIX tank
• Ease of service thanks to the new flange

Technical characteristics:

• Volume of l 30
• Mountingover a sink
• Power of kW 1.5
• Tension B 220
• Max. working temperature of °C 80
• Max. working pressure bar 8
• heating Time ΔT=45 °C of 1 h 10 min.
• Heat losses at ΔТ =65 °C of kWh for 24 Parts 0.61
• Class of protection against water and IPX4 dust
• Overall dimensions (VKHSHKHG) of mm 447x447x410
• Net weight of kg 12.8

Characteristic Ariston BLU EVO R 30/3 Boiler

• boiler Type accumulative (TEN)
• Power, W 1500
• Volume of a tank, l 30
• mounting Type Vertically
• Maximum temperature of heating, °C 80
• heating Time 1 h 10 min.
• tank Material steel with an enamel covering
• Type of the heating element wet TEN
• Magnesium anode is
• Quantity of ten 1
• Country of origin Italy

• boiler Type accumulative (TEN)
• Power, W 1500
• Volume of a tank, l 30
• boiler Form rectangular
• Installation type wall
• mounting Type Vertically
• Eyeliner lower
• Type of management mechanical
• Maximum temperature of heating, the °C 80
• heating Time 1 h 10 min.
• tank Material steel with an enamel covering
• Type of the heating element wet TEN
• Magnesium anode is
• Class of security of the boiler IPX4
• Quantity of ten 1
• Pressure, bar 8
• Dimensions (VKHSHKHG), mm 447х447х389
• Weight 12.8
• Colour White
• Colour (main) White, Blue (blue)
• Country of origin Italy
• Guarantee for TEN, month 12
• Garatiya on a tank, month 36
